Pressure Transmitter 1800V For Refrigeration Machines PCM391

Overview

PCM391 pressure transmitter is specially designed for small and medium-sized equipment applications such as booster pump, air compressor and air conditioning system. It is also applicable to a wide range of industrial applications in a variety of structures, outputs and pressure connections, which meets most application requirements. It has the compact structure which is especially suitable for the installation in the small spaces.


Features

Compact structure

Digital circuit compensation

Strong anti-interference and excellent long-term stability

Small diameter, small size, easy to install and use

Available for measurement of absolute pressure, gauge pressure and sealed gauge pressure

Multiple electrical connection options

SS316L Diaphragm

Suitable for mass production

Specialized for refrigeration machines, withstand voltage 1800V



Applications

Air compressor

Hydraulic and pneumatic equipment

Servo valve and transmission

Air-conditioning system

Pipeline system


Product Parameters


Performance parameters

Pressure range

1Mpa &,1.6Mpa;2.5Mpa

Pressure reference

Gauge pressure, Absolute pressure, Sealed gauge pressure

Accuracy

±0.5%FS(typ.); ±1%FS(max.)

Hysteresis & repeatability

≤±0.1%FS

Temperature drift

≤±1.5%FS(-20℃~85)

Response time

100ms

Service life

106 pressure cycles

Ambient temp.

-20℃~80

Medium temp.

-30℃~105

Storage temp.

-40℃~120

EMC-interference

IEC 61000-6-3

EMC-immunity

IEC 61000-6-2

Insulation resistance

100MΩ/500VDC(200MΩ/250VDC)

Vibration resistance

Sine curve: 20g, 25Hz2kHz; IEC 60068-2-6

Random: 7.5grms, 5Hz1kHz; IEC 60068-2-64

Shock resistance

Shock: 10g/11ms; IEC 60068-2-27

Free fall: 1m; IEC 60068-2-32

Protection

IP65

Material

Wetted part: ASTM S31603 (AISI304)

Housing: ASTM S30400 (AISI304)

Electrical connection: PA66

Weight

50g90g

Withstand voltage

1800V AC/1min
